Image Dynamics IDQ10V3.D2 - SOLD

Specification from
Impedance: Dual 2 ohms
Power Range:50 - 500 Watts RMS
Mounting Depth: 5.75"
Mounting Diameter: 9.60"
Sealed Enclosure Range: .55cu.ft. - 1.1cu.ft
Ported Enclosure Range: 1.0cu.ft. - 1.5cu.ft.

Re- DC Reistance: 1.025/ 4.1 Ohms
Fs- Resonant Frequency: 25.528 Hz
Qes- Electrical "Q": .470
Qms- Mechanical "Q": 2.100
Qts- Total "Q": .384
Vas- Equivalent volume: 2.5cuft (71 liters)
Xmax- One way linear: 19.0mm
Sd- Cone Area: 399.1 cm2
Splo- Sensitivity: 85dB

Link to ID's website:


 Bought this directly from Image Dynamics early this year.  But decided to use their dual 4 ohms version instead.  Installed and used in my setup for a couple of month before switching it out.  Still pretty much new with original box/packaging.

Asking $160 shipped to Cont. USA via UPS/FedEx ground

Payment via Paypal and shipped to Paypal verified address only.

Please contact me if interested.
Thank you.

Any of the pictures can be enlarged by clicking on them.
